ICPT-1000

pLASMAsONIC

ICPT -1000 , 1 MW Induction plasma wind tunnel

ICPT-1000 provides top performance to researcher which desires the high level of industrial automation and system performance.

System Overview

ICPT - 1000

ICPT-1000 provides top performance to researcher which desires the high level of industrial automation and system performance.

  • Key features:
  • 1000 kW plate power induction plasma
  • Large test chamber with multiple view ports for various non-intrusive instruments.
  • Advanced 3 axis displacement system with 6 rotative arms allowing to test multiple test samples and performing intrusive measurements without interrupting the plasma discharge
  • High performance dry vacuum pump s ystem
  • Fully automated operator interface
  • User friendly and versatile system
Download Brochure
System specification

ICPT - 1000

  • Plate Power:

1000 kW

  • Plasma Gas:

Ar/Air (CO2/Ar, O2/Ar possible)

  • Dimensions (L × W × H)

12.5m x 5.6m x 4 m

  • Max torch pressure:

3 bar

  • Torch enthalpy:

Min: 3 MJ/kg and Max: 25 MJ/kg

  • Chamber pressure:

10-1000 mbar

  • Duration

Continuous

  • Test Sample Size :

up to 75 mm dia

  • Heat Flux :

up to 10 MW/m2

Download Brochure
  • Stagnation Pressure :

up to 3000 mbar

  • Estimated Capacity:

up to 40 tests/day

System Overview

ICPT - 15

The ICPT-80 unit is a mid-size unit capable of testing larger test sample at higher stagnation point. The design is done to keep the cost to a minimum while keeping the performance of a larger system.

  • Key features:
  • Compact and low cost
  • Versatile
  • User friendly
  • High purity plasma discharge
Download Brochure

System specification

ICPT - 15

  • Plate Power:

15 kW

  • Plasma Gas:

Ar/Air (CO2/Ar, O2/Ar possible)

  • Dimensions (L × W × H)

X

  • Torch enthalpy:

Min: 3 MJ/kg and Max: 8 MJ/kg

  • Chamber pressure:

10-1000 mbar

  • Duration

Continuous

  • Test Sample Size :

Up to 10mm dia

  • Heat Flux :

up to 4MW/m2

Download Brochure
  • Stagnation Pressure :

up to 750 mbar

  • Estimated Capacity:

up to 20 tests/day
